8t/h Sodium Chloride Triple-Effect Evaporative Crystallizer: A Chemical Plant Success Story

H1: How a Leading Chemical Manufacturer Achieved 40% Energy Savings with CONQINPHI’s 8t/h Sodium Chloride Triple-Effect Evaporative Crystallizer

In the highly competitive chemical processing industry, efficient sodium chloride triple-effect evaporative crystallizer systems have become the cornerstone of sustainable manufacturing. When a major chemical plant in Southeast Asia faced mounting pressure to reduce operational costs while maintaining strict product purity standards, they turned to CONQINPHI for a customized solution. This case study examines how our sodium chloride evaporative crystallizer technology transformed their production line, delivering measurable results that exceeded expectations.

The client, a mid-scale chemical manufacturer producing over 50,000 tons of sodium chloride derivatives annually, struggled with outdated single-effect evaporation equipment that consumed excessive steam and required frequent maintenance. After a comprehensive site assessment, our engineering team recommended an 8t/h sodium chloride triple-effect evaporative crystallizer designed specifically for their chloride-rich wastewater recovery process. Within six months of installation, the plant reported significant improvements in both energy efficiency and crystal quality.

H2: Project Background and Technical Challenges

H3: Understanding the Client’s Requirements

The chemical plant’s existing evaporative crystallizer setup consisted of aging forced-circulation units that operated at low thermal efficiency. Their primary challenges included:

• High steam consumption: The old system required 1.2 tons of steam per ton of water evaporated, driving utility costs to unsustainable levels

• Inconsistent crystal size: Product quality varied between batches, affecting downstream processing and customer satisfaction

• Corrosion issues: Chloride-rich environments accelerated equipment degradation, leading to unplanned downtime

• Limited capacity: Peak production demands often exceeded the old system’s 5t/h throughput capability

The facility needed a robust triple-effect evaporative crystallizer capable of handling 8 tons per hour feed rate while operating reliably in a corrosive chemical environment. Product specifications demanded sodium chloride crystals with purity above 99.5% and uniform particle size distribution between 0.3-0.8mm.

H3: CONQINPHI’s Customized Engineering Approach

Our technical team conducted a three-week on-site evaluation, analyzing feed composition, steam availability, cooling water parameters, and existing infrastructure. Based on this data, we engineered a fully integrated sodium chloride triple-effect evaporative crystallizer system featuring:

• Titanium-grade heating tubes resistant to chloride corrosion, extending equipment lifespan beyond 15 years

• Optimized falling film evaporation design maximizing heat transfer efficiency across three pressure-staged effects

• Advanced crystal growth chamber with precise temperature gradient control for consistent particle formation

• Automated PLC control system with remote monitoring capabilities for real-time process optimization

The system was designed to utilize available waste heat from the plant’s existing boiler system, further enhancing overall thermal economy.

H2: System Design and Implementation

H3: Technical Specifications of the 8t/h Installation

The installed sodium chloride evaporative crystallizer system comprises three interconnected evaporation effects operating at progressively lower pressures. Key technical parameters include:

The triple-effect evaporative crystallizer configuration allows vapor generated in the first effect to serve as heating steam for the second effect, and similarly from the second to the third. This cascading energy recovery mechanism achieves a specific steam consumption approximately 70% lower than conventional single-effect systems.
